SCMA

WEDGING AND CHUNKING MACHINE

orange slicer-dicer icon

MELON, PINEAPPLE

yellow pineapple melon icon
side view of the slicing-dicing machine model SCMA
gray outline stainless steel icon

stainless steel

gray outline glass and fork icon

for food

TECHNICAL FEATURESSCMA
Production capacity18 - 20 fruits/ min
Machine dimensions (width x length x height)750x4800xH2100 mm
(29.5x189xH83 in)
Installed power2,2 kW
Weight950 kg (2095 lb)
Air consumption8 bar - 130l/min
Loading height1000 mm (39.4 in)
Wedges4 - 7
Chunks15-30 mm (0.59-1.18 in)
Employee operator1

The SCMA is a semi-automatic machine designed for cutting melon and pineapple into wedges and chunks.
The operator loads the peeled and halved fruits on an infeed conveyor belt. The machine has a loading belt with two stations and two cutting units: the first cutting unit is a guillotine and performs the horizontal cut. The second cutting unit has circular rotating blades and performs the vertical cut creating fruit wedges. By activating both cutting units, the fruit will be cut into chunks.
In the event that only wedge cutting is desired, the first station can be deactivated.

See technical features
